CombiMax HD
CombiMax HD
VERSATILE MOBILE WASTE COMPACTOR FOR HEAVY DUTY
Europress Combimax HD is a versatile mobile waste compactor for active use. It is easy to operate and designed to meet various waste management requirements. The Combimax HD model is a special design for Heavy Duty. The complete compactor body and ram constructions are reinforced to be able to handle hard material, such
as wooden pallets or hard mixed waste. It’s an ideal solution for example at DIY stores or logistic centres.
The Combimax HD are available in several standard container capacities: 10 m³, 14 m³, 17m³, 20 m³ and 22 m³. Europress Combimax HD can be supplied with a range of accessories e.g. bin lifts and wheels. Special Low Feed variant is available with its infeed height lowered by 180 mm for easy loading from the ground level.
Intelligent SMART technology on the compactors contributes to more cost-efficient and safe operation. Device settings can be individually adjusted to best meet various waste management requirements. The compactors monitor their usage and adapt to anomalies in order to protect both the operator and the components.
CombiMax HD compactors feature Europress SMART connectivity readiness as standard, enabling integration to the Europress SMART Fleet Management system. The system provides insights on asset data and tools for streamlined fleet management.
Highlights
Additional Information
Technical Specifications
(Hopper 4, platform 1200 mm)
400 V, 50 Hz, 3×C32 A*
Standard accessories
- Blue color RAL 5017
- Standard filling hopper
- Lift hooks front / rear
- Intelligent SMART technology
- Europress SMART connectivity readiness
Optional accessories
- Custom RAL color
- Guide rails
- Additional controls e.g. emergency stops
- Rollers front / rear (roll-off)
- Custom filling hopper
- Drainage system
- 2-phase discharge door opening mechanism
- Long handle discharge door opening mechanism
- Top hinged discharge door
- Ozone generator / cooler device (odor control)
- Bin lift (integrated / stationary)
- Lid opening system (hydraulic / electronic)
- Code start system
- Auto start system
- 7.5 kW power unit
- Water proof set up
- Low feed set up
Measurements
Width 2,500 mm
Height 2,730 mm
Weight 3,840 kg
Width 2,500 mm
Height 2,730 mm
Weight 4,050 kg
Width 2,500 mm
Height 2,730 mm
Weight 4,220 kg
Width 2,500 mm
Height 2,730 mm
Weight 4,360 kg
