Scaletipper X1-Tipping Device

Scaletipper X1-Tipping Device

EUROPRESS SCALE SYSTEM

Europress SMART Scale System for tipping devices is a state-of-the art weighing system for waste compactors and waste handling. It is easy to operate and designed to meet various waste management requirements. The system is fully integrated and makes it easy to track the waste-flow of each user that’s been granted access to the system.

The tipping devices can be used with bins from 140L to 1100L, and each and every bin will be weighed and registered in our SMART Scale system. The system allows multiple users and a wide range of reporting options.

Europress Scale System can be delivered to all Europress tipping devices and waste compactors which use the 2-phase tipping device. The turn-key system is fully integrated in the Europress SMART platform, both our website and our SMARTwaste APP.

Highlights

Additional Information

Technical Specifications

Maximum lifting weight
440 kg
Weight accuracy
1.0 kg
Lifting cycle time
35 s
Bin size options
140-1100 l
Reporting options
SMART / XLS / PDF
Power supply
400 V, 50 Hz, 3x C16 A

Standard accessories

  • CAPACITY OF 440 KG
  • DURABLE CONSTRUCTION
  • OFF-CENTRE LOAD ADJUSTED
  • HIGH ACCURACY
  • AUTOMATIC PERIODIC REPORTS

Optional accessories

  • CUSTOM RAL COLOR
  • SAFETY BARS AND/OR SCREEN/CAGE
  • LID OPENING SYSTEM (HYDRAULIC OR ELECTRONIC)
  • ADDITIONAL CONTROLS E.G. EMERGENCY STOPS

Measurements
